1305L stainless steel vessel
General
| Item number | MTL1250RW |
| Condition | Factory new |
| Capacity | 1305 l |
| Maximum density | 1.4 Kg/dm³ |
| Delivery time | Ex stock 2-3 days, otherwise approx. 25 business days |
Technical data and dimensions
| Max. operating pressure acc. to type plate | Atmospheric |
| Maximum operating temperature | 95°C |
| Inner diameter | 1080mm |
| Outer diameter | 1084mm |
| Cylindrical height | 1250mm |
| Height outlet to floor | 300mm |
| Total height | 2005mm (plus agitator motor) |
| Total width | 1084mm |
| Height of feet | 425mm |
Description
| Item number | MTL1250RW |
| Type of item | Factory new stainless steel vessel with agitator mounting |
Material
| In contact with product | Stainless steel AISI304 |
| Other parts | Stainless steel AISI304 |
Design
| Type of construction | Standing on feet |
| Number of fixations | 4 feet |
| Material feet/castors | Stainless steel AISI304 |
| Extras | Dome cover Ø 400mm, aeration and deaeration valve, DN50 DIN11851 connection piece, agitator flange connection piece IEC200 |
Features
| Design | Single-jacket |
| Insulated | No |
| Pressure vessel | No |
| Spray head(CIP) | No |
| Technical drawing / documentation | Yes |
| Type plate | Yes |
| Outlet | DN50 DIN11851 |
| Outlet valve | Ball valve or disc valve (selectable) |
Agitator
| Agitator | No |
